Product Details

Size

Micro ATX

Type

Desktop

Processor

Supported Processors

Intel

Models

Celeron Dual Core, Core i3, Core i5, Core i7, Core i9, Pentium Dual Core

Supported CPU Generation

Alder Lake, Raptor Lake

Socket

1700

Chipset

Model

Intel B760

Memory

Memory type

DDR4

Quantity

4 DIMM Slots

Memory Speeds

2133 MHz, 2400 MHz, 2666 MHz, 2800 MHz, 2933 MHz, 3000 MHz, 3200 MHz, 3333OC MHz, 3400OC MHz, 3466OC MHz, 3600OC MHz, 3733OC MHz, 4000 MHz, 4000OC MHz, 4400 MHz, 4400OC MHz, 4600OC MHz, 4800 MHz, 4800OC MHz, 5000 MHz, 5000OC MHz, 5066OC MHz

Memory Channels

Dual Channel

Internal Connectors

PCI Express x16 4.0

1 Slot

PCI Express x16 5.0

1 Slot

SATA III 6Gb/s

4 Port

M.2 Slots

0

M.2 Type

2 PCIe 4.0 Ports

External Connectors

Rear USB-A outputs

2 USB 2.0 Ports, 5 USB 3.2 Ports

Rear USB-C outputs

1 USB 3.2 Port

Ethernet (LAN)

1

Screen Connections

DisplayPort, HDMI

Specifications

RGB Lighting

Yes

WiFi/Bluetooth

No

Sound

Sound Card Channels

7.1

Additional Audio Connections

Optical S/PDIF
